Why logging data?

Logging serves several purposes essential to maintaining secure and reliable DNS operations:

Troubleshooting:

Quickly identifying and resolving technical issues.

Security monitoring:

Detecting abuse, such as DDoS attacks or malicious queries.

Performance optimization:

Monitoring server performance to ensure reliability.

Abuse prevention:

Preventing misuse of our infrastructure by tracking suspicious activities.

---

What data is logged?

Certain categories of logs are disabled by default to prioritize privacy:

General Operations (default):

Completely disabled, no general system activity is logged.

Queries (queries):

Disabled, no logs are maintained of regular DNS requests.

Query Errors (query-errors):

Disabled, no information about failed queries is logged.

The following logs are active and include data about client IP addresses, the domains being queried, and the specific actions taken by the server. Below is an overview of the active logging categories:

Authentication Server Logs (auth_servers_log):

Logs interactions between DNS servers (e.g., trust and authentication).

DNSSEC Logs (dnssec_log):

Records related to DNSSEC (Domain Name System Security Extensions), such as signing and validation events.

Zone Transfer Logs (zone_transfers_log):

Logs information about zone file transfers between servers.

Dynamic DNS Logs (ddns_log):

Tracks updates made through Dynamic DNS.

Client Security Logs (client_security_log):

Logs related to potentially unauthorized or malicious DNS requests, including source IPs and queried domains.

Rate-Limiting Logs (rate_limiting_log):

Records requests blocked due to exceeding rate limits.

RPZ Logs (rpz_log):

Tracks queries affected by Response Policy Zones (RPZ), often used to block or redirect malicious domains.

Debug Logs (default_debug):

Detailed logs used for debugging, only activated when necessary.

---

Retention and rotation policy

Logs are stored in files with a maximum duration of one day (24 hours) per file.

---

What does this mean for you?

Logged Data:

For active logging categories, client IP addresses, the domains queried, and other technical details are logged.

Disabled Logging:

Regular DNS queries and errors are not logged (queries and query-errors are null).

---

Security and sharing

All logs are stored and accessible to the server administrators. They are never shared with third parties, and their use is limited to operational purposes.

1. Access the FritzBox web interface

Open a web browser and go to http://fritz.box or http://192.168.178.1 (depending on your FritzBox model).
Log in with your administrator credentials (username and password).

2. Navigate to the DNS settings

In the main menu of the FritzBox interface, go to "Internet".
Then, click on "Account Information" or "Connection Settings" (the exact name may vary depending on the FritzBox model).
Look for an option labeled "DNS Server" or "DNS Settings".

3. Configure the DNS servers

In the DNS settings section, you will typically find an option to either "Obtain DNS server addresses automatically" or to "Use the following DNS server addresses".
Select "Use the following DNS server addresses" to manually set your DNS servers.
Enter the IP addresses of your DNS servers:

Primary DNS:

85.215.153.54

Secondary DNS:

87.106.35.241

4. Save the configuration

After entering the DNS server addresses, click "Apply" or "Save" to save the settings.
The FritzBox will apply the new DNS settings to the network.

1. Install packages


											apt install resolvconf -y



2. Open config file


											nano /etc/resolvconf/resolv.conf.d/head



3. Add nameservers


											nameserver 85.215.153.54
											nameserver 87.106.35.241



and/or


											nameserver 2a01:239:251:a800::1
											nameserver 2a00:da00:f425:5800::1



4. Restart service


											resolvconf --enable-updates
											resolvconf -u



Configure DoT Using the Private DNS Setting (Android 9 and Newer)

Android 9 (Pie) and later have built-in support for DNS-over-TLS via the Private DNS feature. This method works system-wide for both Wi-Fi and mobile data.

Steps:

1. Open the Settings app
2. Navigate to Network & Internet
3. Select Private DNS
   • If you don’t see this option, it may be located under Advanced or Connections depending on your device.
4. Choose Private DNS provider hostname
5. Enter the hostname of the DoT provider:

   •
     														dns.dremaxx.de



6. Tap Save

Your Android device will now use DNS-over-TLS for all network connections.
